Hydrawise EZ Decoder Output Module for HCC, PRO-C and ICC2

Features Two-wire decoder system for HCC, PRO-C and ICC2 controllers Up to 54-station capacity, plus master valve No special wire or connectors required Allows hybrid operations of conventional and decoder stations (54 total stations max per controller) Programmable decoders with no serial numbers Wire paths possible for over 1 km; see wiring table No special grounding or surge arrestors required in-line EZ-1 single-station decoders have status LED for positive diagnostics P/MV can be activated by decoder or direct controller output EZ-DM output module works in any controller module slot Electrical Specs Electrical output on two-wire path: 24VAC~, 50/60 Hz Up to two standard 24VAC solenoids per EZ-1 decoder output Simultaneous stations on: Two, plus master valve Wire paths to field: Two (each may be tee-spliced in different directions) Earth grounding: Ground the controller as usual (no grounding required in the decoder line) System is compatible with DUAL-S surge arrestors if desired EZ-1 Decoders are IP68, submersible Compatible Controllers HCC (including Hydrawise™ internet control) ICC2 (including Centralus™ internet control) PRO-C (including Hydrawise™ internet control) Overview Cost and complexity have often limited decoder technology to higher-end systems. However, with the revolutionary EZ Decoder System (EZDS), you get all the advantages of two-wire installations with simpler, more cost-effective technology — so you can bring the power of two-wire control to more projects than ever before. EZDS is compatible with all the features of our Hydrawise™-enabled HCC controller, as well as the ICC2 controller and its web-based Centralus™ management platform. Plug in the EZ-DM two-wire output module to enable up to 54 stations of irrigation, plus a master valve, on a single pair of wires. Then simply place EZ Decoders at each valve! EZ Decoders are small, waterproof, and come with color-coded wiring and a convenient LED status light. They do not require special wire or connectors to function. Better yet, the system can coexist with conventional output modules, allowing hybrid functionality of both direct-wired valves and decoder operations in the same controller. This technology also permits easy conversion of a conventionally wired system to two-wire using the existing wiring bundle. It’s that easy! Wiring Table International Wire (mm2) Distance (meters) 0.8 mm2 267 1 mm2 333 1.5 mm2 500 2.5 mm2 833 4 mm2 1,333
