RGBlink EcoSystem PTZ VUE 20x & Control

Description RGBlink EcoSystem PTZ VUE 20x & Control Set including VUE PTZ camera 20x optical zoom and PTZ Camera Control. The RGBlink EcoSystem PTZ VUE 20x & Control consists of the PTZ Camera Control and the VUE PTZ Camera 20x Optical Zoom. The set is the affordable entry into professional remote camera control and can be expanded with additional PTZ cameras – also from other manufacturers. As the core of the workflow, the RGBlink PTZ Camera Control is the perfect control device for up to 255 PTZ cameras in an IP network. The solid metal design with rubber feet ensures a stable stand. The silicone covered buttons with green backlight offer a very comfortable haptic. The joystick for controlling camera movements works very sensitively in 8 directions. A zoom controller and a lock button are also integrated. A two-line, blue backlit LCD display shows the current setup. RGBlink VUE PTZ Camera 20x Optical Zoom The RGBlink VUE PTZ Camera 20x Optical Zoom is a professional broadcast PTZ camera in a sleek black design with a tally LED light on top. With its fast, silent rotation and zoom function, it is ideal for smaller productions, live events or in the education sector. Video output is via HDMI, 3G-SDI, USB 2.0 or IP streaming via network at up to 1080p60. Even in low-light conditions, it delivers top-notch image quality with rich colors thanks to dynamic noise reduction. The lens’ high zoom factor and intelligent, fast autofocus allow for sharp distance shots. Connections The camera has one HDMI, 3G-SDI, USB and network port each, simultaneously outputting video signals at a maximum of 1080p60. Connected to a PC via USB, the camera is recognized as a UVC webcam without driver installation. It can be immediately integrated into OBS-Studio for streaming or into Zoom, MS-Teams or similar for video conferencing. The video signal can be output at 720p or 1080p with the frames common in broadcast. Optionally, date, time and the individual camera name can be displayed in the image. Audio signals from a microphone or line-in device are embedded in the HDMI, SDI or network stream via the 3.5 mm stereo jack. Power is supplied to the camera via the included AC adapter, or alternatively via LAN thanks to the PoE function if Power over Ethernet is supported by the router. Tally LED On the top of the camera there is a tally LED light in green or red, which is clearly visible from all sides. In combination with the RGBlink Mini Pro or other tally control units, the standby or on-air status is displayed in color. Configuration via remote control or web browser The camera can be put into operation immediately with the default settings. With the supplied remote control, a great many settings can be configured via the On Screen Display menu control, which is displayed via HDMI or SDI on a connected monitor. Activating DHCP or manually entering the IP address as well as adjusting brightness, contrast, resolution or frame rate is a significant convenience here. The advanced configuration of the camera is carried out via password-protected access using a web browser. Audio, video and network parameters can be adjusted and firmware updates can be performed via the well-structured menu navigation in German or English. Numerous image settings such as focus, exposure, color space, gamma, etc. can be changed from auto mode to personal preferences and saved. Streaming The RGBlink VUE PTZ Camera can simultaneously output two streams with different network protocols, codecs, resolutions and frames. The available protocols are RTMP, RTSP, SRT or RTP, the codecs are H.264 or H.265, the bitrate is variable adjustable. The videos can be streamed directly to the Intranet or Internet and picked up by appropriate hardware or software (e.g. OBS Studio). Control via remote control, web browser or controller The camera supports a variety of control methods: The most convenient way to control the camera is via the included IR remote control, so no network setup is required for a quickly set up setup. The remote controller can control up to four RGBlink PTZ cameras, including older models, and adjust key parameters via a menu. The controller offers pan and tilt, zoom, manual focus, and save and recall of different viewing angles. If the camera is connected to a network, it is possible to control it via the web browser tool. The video stream is displayed on the PC monitor and allows easy image control. Professional control is provided by optional external controllers via serial RS232 / RS485 or network interface with VISCA or Pelco protocols. The RGBlink Mini Pro also provides professional control with an integrated joystick and zoom rocker, plus it automatically triggers the camera’s tally LED light when switching. Green light signals the next cut to the camera – red light on-air. In conjunction with the free RGBlink Xpose app, the PTZ camera can be operated on WLAN via PC, Mac, iPhone or Android smartphone. The camera allows you to save and recall up to 254 different angles to quickly switch between different perspectives. Mounting The optional RGBlink PTZ Camera Wall Mount Bracket allows the camera to be mounted upright on a wall. Alternatively, the optional RGBlink PTZ Camera Upside Down Mount offers ceiling mounting, where the camera is suspended. In the camera menu, the video output can be mirrored horizontally. The ¼ inch tripod thread located in the camera base allows mounting on suitable video tripods. Parking position in stand-by In standby mode, the lens rotates vertically downward to signal power saving mode. This parking position also provides safe transportation of the camera. Features: High image quality with dynamic noise reduction in low light conditions High-speed optical zoom Full HD resolution with up to 60 frames/sec simultaneously on all video outputs Embedded audio in HDMI, SDI and network streams H.264/H.265 dual streaming with all relevant network protocols Tally LED light on top OSD menu with manual IP entry/DHCP activation via remote control Administration via web browser PTZ camera control via VISCA or Pelco protocols Power supply via PoE or AC-adapter (included) Power saving sleep function with parking position of lens vertically downwards 1/4″ tripod thread on the bottom side Suitable for wall or ceiling mounting (accessories not included) Technical Data: Interface  Output 3G SDI: 1xBNC HDMI: 1xHDMI-A USB: 1xUSB-A LAN: 1xRJ45 (supports PoE) Audio IN: 1×3.5mm Stereo Jack Control RS232 IN/OUT: 2xDIN8 RS485: 1x4pin Terminal Power: 1xDC12V Jack Video formats 1080P60, 1080P50, 1080I60, 1080I50, 1080P30, 1080P25, 720P60, 720P50, 1080P59.94, 1080I59.94, 1080P29.97, 720P59.94 Camera Optical Zoom: 20x, f＝5.05～91.50mm View Angle: 3.45°～ 60.04° AV: F1.8 ～ F2.9 Digital Zoom: 10x Minimum Illumination: 0.5Lux (F1.8, AGC ON) Digital Noise Reduction (DNR): 2D & 3D DNR White Balance: Auto/Manual/One Push/3000K to 7000K (selectable) Focus: Auto/Manual Aperture/Electronic Shutter: Auto/Manual BLC: ON/OFF WDR: OFF/Dynamic Level Adjustment Video Adjustment: Brightness/Color/Saturation/Contrast/Sharpness/B/W mode/Gamma curve SNR: >55dB Effective Pixels: 2.07m, 16:9 Pan-and-Tilt Parameter Pan/Tilt Movement: -170°～ 170° / -30°～ 90° Pan/Tilt Control Speed 0.1～60°/sec. / 0.1～30°/sec. Preset Speed/Quantity: Pan:60°/sec., Tilt:30°/sec.; up to 255 preset positions (10 with remote control) TALLY-LED: full 360° view of TALLY Supported Standards Audio Compression Formats: AAC | MP3 | G.711A Video Compression Formats: H.264 | H.265 | Dual Streaming Output Output Resolutions: 1080p60/59.94/50/30/29.97/25 | 1080i60/59.94/50 | 720p60/59.94/50 Control Protocols: VISCA | Pelco-D | Pelco-P Baud Rate (bps): 115200 | 9600 | 4800 | 2400 Network Protocols: RTSP | RTMP | ONVIF | GB/T28181 | VISCA Additional Standards: SDI SMPTE 425M (Level A & B) | SMPTE 424M | SMPTE 292M | SMPTE 259M-C | DVB-ASI Power  Input: DC12V/1.5A Max. Power: 12W Environment Conditions Temperature: -10℃～50℃ Humidity: 20%～80% Dimensions/Weight Dimensions (WxDxH): 180mm x 188mm x 198mm Weight: 1.7kg PTZ Camera Control As the core of the workflow, the RGBlink PTZ Camera Control is the perfect control device for up to 255 PTZ cameras in an IP network. The solid metal design with rubber feet ensures a stable stand. The silicone covered buttons with green backlight offer a very comfortable haptic. The joystick for controlling camera movements works very sensitively in 8 directions. A zoom controller and a lock button are also integrated. A two-line, blue backlit LCD display shows the current setup. Features: Multiple control and network protocols LCD screen on front panel with keypad tone Customer modifiable control code Joystick control of camera speed Adjustment of camera parameters via buttons Multiple control ports for up to 255 cameras Supports PoE Technical Data: Connectors Communication: RS232: 1x DB15 RS422 (RS485): 1x 5pin Terminal LAN: 1x RJ45 Performance: Control Protocols: VISCA | Pelco-D | Pelco-P Network Protocols: ONVIF | VISCA Baud Rate (dps): 2400 | 4800 | 9600 | 19200 | 38400 | 115200 Display: LCD Screen Key Tone: ON/OFF Joystick: Four dimensions (control: up, down, left, right, zoom, rotation) Upgrade: WEB upgrade Power: Input Voltage: DC12V Max Power: 6W Environment: Temperature: -10°C ~ 50°C Humidity: 0% ~ 90% Dimensions: 320mm x 179.3mm x 109.9mm
