Automat Double Union PVC Ball Valves

Features True union design for easier installation or repair, without expanding the pipe system. User friendly design allows smooth operation of handle. Union nut load does not transfer onto ball. Free from vibration or chattering during opening and closing of valve. In built Spanner wrench on Handle for valve dissemble /assemble. TPE Seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque. Chemical/Corrosion resistant, Color UV stabilized Dimensions (as pictured) Dimensions Size BSP dk D I L Lt E H 25mm (1" ) 33.4 32 68 23 55.5 108 80 62 40mm (1 1/2" ) 48.26 50 94.4 32 76.6 148.8 121 88.3 50mm (2") 60.33 63 116 35.4 88 175.4 149.9 97 65mm(2 1/2" ) 73.03 75 131.6 30.45 108.4 186.7 162 106 80mm(3") 88.9 90 176.8 43.4 140 213.8 198.3 139
